NEW

COMPACT

CROSSOVER



PRODUCT FEATURE

COLOR VARIANT

Rp. 163.000.000

MAT GUNPOWDER BLACK METALLIC

SPECIFICATION DETAIL

Dimension

2,156 x 828 x 1,412 mm

Fuel Tank Capacity

17,7 L

Ground Clearance

181 mm

Curb Weight

198 kg

Seat Height

834 mm

Wheel Base

1.443 mm

Engine Type

Liquid-Cooled, 4-Stroke, DOHC Parallel Twin-Cylinder

Displacement

471,03 cc

Fuel Supply System

PGM-FI (Programmed Fuel Injection System)

Bore x Stroke

67 mm x 66,8 mm

Compression Ratio

10.7 : 1

Max. Power

37 kW/8,500 rpm

Max. Torque

44.6Nm/6,500 rpm

Transmition

Constant mesh, 6 speed

Starting system

Electric

Clutch Type

Wet, multiple with coil spring

Oil Capacity

2,4 L (Periodic Exchange)

Frame Type

Diamond, Steel

Front Tires Size

110/80R19M/C (59H)

Rear Tires Size

160/60ZR17M/C (69H)

Front Brake Type

Hydraulic, Single 310mm Wavy Disc with Two Piston Calipers

Rear Brake Type

Hydraulic, Single 240mm Wavy Disc with Single Piston Calipers

Brake System

ABS 2 Chanel

Front Suspension Type

Showa, 41 mm Telescopic Fork (Long Travel), Adjustable

Rear Suspension Type

Swing arm, adjustable Showa monoshock with Prolink

Ignition Type

Full Transisterized, Battery

Spark Plug Type

NGK CPR8EA-9

Front Headlight

Hi 12 W x 1 (LED)

Rear Headlight

Low 4,8 W x 1 (LED)
