NEW

STREET

FIGHTER STYLE



PRODUCT FEATURE

COLOR VARIANT

Rp. 147.000.000

MAT GUNPOWDER BLACK METALLIC

SPECIFICATION DETAIL

Dimension

2,081 x 792 x 1,056 mm

Fuel Tank Capacity

17,1 L

Ground Clearance

144 mm

Curb Weight

189 kg

Seat Height

789 mm

Wheel Base

1.409 mm

Engine Type

Liquid-Cooled, 4-Stroke, DOHC Parallel Twin Cylinder

Displacement

471,03 cc

Fuel Supply System

PGM-FI (Programmed Fuel Injection System)

Bore × Stroke

67 x 66.8 mm

Compression Ratio

10.7 : 1

Max. Power

37 kW/8,500 rpm

Max. Torque

44.6 Nm/6,500 rpm

Transmission

Constant mesh, 6 Speed

Starting System

Electric

Clutch System

Wet, Multiple with Coil Spring

Oil Capacity

2,5 L (Periodic Exchange)

Frame Type

Diamond, Steel

Front Tires

120/70ZR17M/C (58W)

Rear Tires

160/60ZR17M/C (69W)

Front Brake

Hydraulic, Single 320 mm Wavy Disc with Two Piston Calipers

Rear Brake

Hydraulic, Single 240 mm Wavy Disc with Single Piston Caliper

Brake System

ABS 2 Channel

Front Suspension

Showa, 41 mm Telescopic Fork, Adjustable

Rear Suspension

Swing Arm, Adjustable Showa Monoshock with Prolink

Ignition Type

Full Transisterized, Battery

Spark Plug Type

NGK CPR8EA-9

Front Headlight

Hi 12 W x 1 (LED)

Rear Headlight

Low 4,8 W x 1 (LED)
