NEW

SUPER-AGGRESIVE

SPORT STYLE



PRODUCT FEATURE

COLOR VARIANT

Rp. 155.000.000

GRAND PRIX RED

SPECIFICATION DETAIL

Dimension

2,081 x 758 x 1,145 mm

Fuel Tank Capacity

17,1 L

Ground Clearance

130 mm

Curb Weight

192 kg

Seat Height

789 mm

Wheel Base

1.409 mm

Engine Type

Liquid-Cooled, 4-Stroke, DOHC Parallel Twin Cylinders

Displacement

471,03 cc

Fuel Supply Sysem

PGM-FI (Programmed Fuel Injection System)

Bore x Stroke

67 mm x 66.8 mm

Compression Ratio

10.7 : 1

Max. Power

37 kW/8,500 rpm

Max. Torque

44,6 Nm/6.500 rpm

Clutch System

Wet, Multiple with Coil Spring

Oil Capacity

2,5L (Periodic Exchange)

Frame Type

Diamond, Steel

Front Tires

120/70ZR17M/C (58W)

Rear Tires

160/60ZR17M/C (69W)

Front Brake

Hydraulic, Single 320 mm Wavy Disc with Two Piston Calipers

Rear Brake

Hydraulic, Single 240 mm Wavy Disc with Single Piston Caliper

Brake System

ABS 2 Channel

Front Suspension

Showa, 41 mm Telescopic Fork, Adjustable

Rear Suspension/td>

Swing Arm, Adjustable Showa Monoshock with Prolink

Ignition Type

Full Transisterized, Battery

Spark Plug Type

NGK CPR8EA-9

Front Headlight

Hi 6,4 W x 2 (LED)

Rear Headlight

Low 3,8 W x 2 (LED)
